Description
| Weight: | 584 lbs |
|
Dimensions:
|
136.4 x 51.6 x 46.3 inches (LxWxH) |
| Feed Volume: | 28 bu |
| Feed weight – wheat/corn: | 1700 lbs |
| Feed weight – barley/pellets: | 1435 lbs |
| Feed weight – oats: | 1150 lbs |
| Tyre size: | 22-11-8 6 Ply |
| Cattle: | 50 |
| Sheep: | 150 |
| Goats: | 150 |
- Reinforced stainless steel troughs
- Reinforced stainless steel upper adjusters
- Solid stainless steel lower adjusters
- 2x adjuster guards standard
- Adjuster guard storage (for when not in use)
- 2 x 1.57 inch SHS stands
- Sheep and cattle height options available
- Z275 sheet metal, stainless steel, and galvanised dipped
- 45-degree angled trough
- Rain protection reinforcing
- Sidewall bracing
- 3 x adjuster braces
- Dual tab adjuster braces
- 4 x locking bolts on the lower adjusters
- Adjuster guard locking system
- Dual positioned adjuster guard for dusty feeds
- 2 x 2.95 inch round sight glasses
- 2x volume stickers
- Adjust feeder height in about 30 minutes
- Cleaning tool supplied
- Tube spanner supplied
- Secure storage for tools
- 2x new tyres
- 93.7 inch trough length
- Painted notch system on the adjusters
- Deep 4.33 inch trough depth
- Gutters on side walls drain out of feeder
- Reinforced roof edges
- Mineral attachment option
- Lamb creep feeding panel option
- Standard operating procedure supplied
- User guide supplied
- Trial reports available
